Flush Door

Ogaan Flush Door

Flush Door: Is: 2202

Ogaan Laminates introduces Flush Door which has a basic structure composed of solid blackboard core, vertical stiles, and horizontal rails that create a pre-fixed frame. The flush door is composed of wooden strips that are placed edge-to-edge and sandwiched between veneers, then bonded under high pressure and temperature using a synthetic resin. So in a simpler term, it is a door that is made of a timber frame covered with ply from both the sides and then the hollow part inside is filled with rectangular blocks of soft wood.
These are made from high density farm timbers which are chemically treated and well seasoned battens are edge glued to make these doors durable and dimensionally stable. FLUSH DOORS has extra lock rail that provides sufficient strength to handles and knobs.

Its hardwood frames provide strength for fitting of hinges and anti deviation resistance. Glue line poisoning makes them resistant to fungus, termite and borer. Flush door undergo extreme testing process as per IS: 2202(1) before going to the market so that the customer can trust the strength and stability.
What are Flush Doors and benefits of using flush doors and its specifications?
Doors are an important requirement and element in every home and should not only be aesthetically pleasing but also have features like durability, strength, water and heat resistance and it should not warp with time. Gone are the days when doors were used for the mere purpose of maintaining privacy and security. Doors these days have become a beautiful structure and integral part of every home’s interiors.


  • Flush door surface is highly resistant to stains, scratches and crash.
  • Ogaan’s flush doors offer a variety of designs and decorative finishes. These doors provide attractive, warm and traditional appearance.
  • These doors are decay proof. Chemical treatment makes the flush door termite and fungi free.
  • These doors are chemically treated and vacuum pressed they are heat and water resistant.

Technical Specifications:

Test Requirement of IS:2202 Test Result
Dimension & Squareness

Length +/0 mm

Width +/0mm

Thickness ± 1mm

Squareness: not more than

1 mm per 600 mm length

+3 mm

+2 mm

+6 mm

.5 mm

General Flatness 6 mm 2.0 mm
Local Plainness 0.5 mm 0.2 mm
Impact Indentation

0.2 mm 0.10 mm
Flexure Test

Max. Deflection 5mm Max. Deflection 3mm
Edge Loading Test

Residual Deflection 0.5 mm

Lateral Buckling 2 mm

Residual Deflection .25 mm

1 mm

Shock Resistance Test Should withstand 5 impacts Can withstand 10 impacts
Misuse Test No permanent deformation

of the Fixing

No Permanent Deformation
End Immersion Test No Delimitation No Delimination
Knife/Glue Adhesion Test Pass Standard Excellent
Screw withdrawal 1000 N 1500 N
Slamming Test No visible damage

after 50 drops

No Damage
Buckling Test Pass Standard Excellent
